High precision filtration: Customized separation filter cartridges have very small pores that can filter out liquid and solid particles with a diameter of 0.3 microns or more, ensuring stable fluid quality after filtration.


Good chemical stability: Customized separation filters usually use special materials and designs, which have good corrosion resistance and chemical stability, and can work stably in complex chemical environments for a long time.


Environmental protection and energy conservation: The separation filter generates less waste during the filtration process, which is beneficial for environmental protection and energy conservation.


High temperature and high pressure resistance: Some models of separation filters can withstand high working temperatures and pressure differentials, such as a working temperature range of -30 ℃ to+110 ℃ and a working pressure differential of up to 21MPa

The material of the separation filter element has lipophilic and hydrophobic properties, which means it allows oil to pass through but blocks moisture. This characteristic allows the oil to pass through the filter element smoothly, while moisture is trapped outside the filter element, thereby achieving oil-water separation.



2. Aggregation and Separation

In the oil-water separation system, the oil first passes through the coalescence filter element, which aggregates tiny water droplets into larger ones. These water droplets settle into the collection tank under the action of gravity. Subsequently, the oil flows through the separation filter element to further remove residual moisture, ensuring that the final discharged oil is clean and free of water.



3. Physical interception and adsorption

The separation filter uses physical interception and adsorption mechanisms to trap solid particles and residual moisture in the oil on the surface or inside of the filter. This mechanism ensures the efficiency and stability of the separation effect.



4. Differential pressure monitoring and maintenance

As the usage time increases, the accumulation of impurities on the separation filter element will lead to an increase in pressure difference. When the pressure difference reaches a certain threshold (such as 0.15Mpa), it indicates that the filter element has been clogged and needs to be replaced to maintain the normal operation of the system.



5. Application scenarios
