Stainless Steel Sintered Filter Element 219x216

Type: Sintered Powder Filter Element
Dimension: 219x216
Material: Stainless steel
Filtration accuracy: 1~50 μm
Interface: Quick installation interface
Description:

The filter element is made of stainless steel wire mesh and sintered together to form a rigid structure. Its design ensures efficient filtration with minimal pressure drop, and the filter aperture is uniform, ensuring efficient and consistent filtration efficiency. Its compact size, high efficiency, excellent corrosion resistance, and harsh environment make it the best choice to meet your filtration needs.

Specifications:
Type Sintered Powder Filter Element
Dimension 219x216
Material Stainless steel
Filtration accuracy 1~50μm
Interface Quick installation interface
:









Features:



1) Has good anti cleaning performance and a relatively long replacement cycle;



2) High temperature resistance (can work up to 900 ℃ environment);



3) Strong corrosion resistance;



4) High impact resistance and alternating loads;



5) Good backwashing effect, easy regeneration of components, etc







 Working principle:



Sintered powder filter element can realize micron-level precision filtration, can separate solid particles in the liquid, gas impurities, when the fluid passes through a certain degree of accuracy of the element, the impurities are blocked on the surface of the element to form a filter cake, pure fluid through the element outflow, so that the contaminated live impurity-containing fluids filtration to the state of the normal production required to ensure that downstream devices to obtain a pure product to live to protect the normal operation of the equipment.



Different from the non-metallic sintered element is that when the surface of the sintered power filter element of the filter cake reaches a certain thickness, because of its high strength performance characteristics, so through a certain reverse pressure on the element to backwash or blowback method to clean the element, the element can be used again.
